Butt Fusion Ball Valves for PE Pipeline Networks
Butt Fusion Ball Valves are used in polyethylene pipeline systems to isolate or control flow. The valve is supplied with PE spigot ends, allowing direct butt fusion welding to HDPE pipes. Once welded, the valve becomes part of the pipeline, creating a continuous connection without threaded or mechanical joints.
These valves are commonly installed in water distribution networks, gas pipelines, irrigation systems, and industrial utility lines where HDPE piping is used throughout the system.
Product Features
Direct Butt Fusion Installation
The valve can be welded directly to PE80 or PE100 pipes using standard butt fusion equipment. No additional adapters or transition fittings are required for installation within an HDPE pipeline.
01
Suitable for Buried Pipework
Because the valve body is manufactured from polyethylene material, it can be installed in underground pipeline systems alongside HDPE pipes.
02
Full Flow Path
The internal flow passage is designed to maintain pipeline capacity and minimize unnecessary flow restriction during operation.
03
Quarter-Turn Operation
Opening and closing is controlled by a 90-degree rotation, making the valve suitable for routine isolation and maintenance work.
04
Compatible with PE Pipeline Systems
The valve is designed for use in polyethylene networks and can be incorporated into new installations as well as pipeline extension projects.
05
Available Configurations
Depending on project requirements, Butt Fusion Ball Valves can be supplied in different configurations:
- Full Bore Butt Fusion Ball Valves
- Water Service Ball Valves
- Gas Distribution Ball Valves
- Long Handle Ball Valves
- Underground Installation Ball Valves
- Customized Valve Assemblies
Special dimensions and operating configurations can be produced according to project specifications.
Typical Applications
Water Distribution Networks
Used to isolate pipeline sections, control maintenance zones, and manage water flow within municipal and regional supply systems.
Gas Distribution Systems
Installed in PE gas networks for shut-off and maintenance purposes at branch connections, service lines, and distribution points.
Irrigation Infrastructure
Suitable for agricultural irrigation projects where polyethylene pipelines are used for water transport and distribution.
Industrial Utility Systems
Applied in cooling water, process water, and general utility pipelines where corrosion-resistant piping materials are preferred.
Infrastructure Projects
Specified in utility and civil engineering projects that utilize welded HDPE pipeline systems.
Technical Specifications
|
Item |
Specification |
|
Material |
PE100 |
|
Connection Type |
Butt Fusion |
|
Size Range |
DN20–DN400 |
|
Pressure Rating |
PN10–PN16 |
|
Operating Media |
Water, Gas, Utility Fluids |
|
Standards |
ISO 4427, ISO 4437, EN 12201, EN 1555 |
Additional sizes and pressure classes can be supplied for specific project requirements.
Manufacturing Information
The valves are produced using PE100 material and assembled with precision-machined internal components. Dimensional checks and operational testing are carried out during production to verify valve performance.
Available services include:
- Standard product supply
- OEM production
- Drawing-based manufacturing
- Customized dimensions
- Export packaging
- Technical documentation support
Material certificates and inspection records can be provided when required.
Common Installation Locations
Butt Fusion Ball Valves are frequently installed at:
- Water supply pipelines
- Gas distribution branches
- Irrigation control points
- Pump stations
- Valve chambers
- Utility service connections
- Industrial pipeline networks
Their welded connection design makes them suitable for projects where polyethylene pipe systems are used throughout the installation.
Request Product Details
For dimensions, pressure ratings, operating conditions, or project-specific requirements, please provide your pipeline specifications or technical drawings.
We can assist with product selection, dimensional information, and quotation support based on your project requirements.
